Lutron Sivoia QS Shades: Control, Integration and Fixes
Sivoia QS is Lutron's motorized shade drive, and it's the part of a house people ask about most once it's a few years old: which system controls it, why one shade stopped answering, and why another stops in the wrong place. One thing to be clear about first: we integrate and control shades. The shade, the fabric and the hardware come from your designer or shade dealer; we make them work with the rest of the house. Everything below is from Lutron's documents.

Wired, wireless and battery
- Sivoia QS (wired): each shade drive is on Lutron's QS link, powered from a QS shade power panel. No batteries, no radio.
- Sivoia QS Wireless: the same drive family on Lutron's Clear Connect radio.
- Triathlon: battery-powered (D cells), on the same radio. Lutron quotes three to five years of battery life, based on two full up-and-down cycles a day (Lutron App Note #561). A red blink every few seconds means the batteries are due within about three months.
Which Lutron system runs which
| System | Shades |
|---|---|
| HomeWorks QSX | wired Sivoia QS on the QS link; Triathlon and Sivoia QS Wireless through a wireless processor |
| RadioRA 3 | Sivoia QS Wireless and Triathlon |
| Caséta | Serena on either hub; the PRO hub adds Sivoia QS, Triathlon and some Sivoia QS Wireless shades |
Wired shades can also have Pico remotes through a QS shade module (up to 10 Picos per module). Older Sivoia drives (QED, Classic) aren't directly compatible with today's systems and are upgraded rather than integrated.
The faults, and Lutron's fixes
Most "the shade is broken" calls are one of these. Lutron's Sivoia QS blink-code guide is the reference for every one.
- It stops in the wrong place, or opens or closes too far. The drive has lost its limits. Lutron's first fix is to set the open and close limits again, at the drive's own buttons (Lutron's limit-setting guide). If it keeps losing them, Lutron says it may be the drive itself.
- A wired shade stopped answering. The drive has a Link Diagnostics mode: a drive that's talking properly answers with a slow green blink, a bad link shows fast red. Lutron's QS wired troubleshooting covers the wiring faults it finds (a missing, shorted or swapped wire at the shade's connector) and the voltages to expect there.
- It stopped after running a lot. The drive protects itself after too much running or when it overheats; Lutron's advice is to wait 20 minutes.
- It stopped partway and blinked red. An obstruction: fabric caught, or something in the way.
- A battery shade creeps down. On Triathlon rollers that's spring tension, with its own Lutron app note (#509).
- A factory reset of a drive keeps its limits. It's for re-assigning the drive, not for fixing a position problem.
Setting limits from the Lutron app is a Caséta and RA2 Select feature; on RadioRA 3 and HomeWorks it's done at the drive or by whoever programs the system.
With Control4
Control4 controls Lutron shades through the Lutron processor, with drivers Control4 writes: a roller-shade driver, and venetian-blind and sheer-blind drivers that bring lift and tilt in as two controls, plus a tilt-only driver (Control4's driver database). So a "Movie" button can lower the shades as part of the scene, and the shades can follow the sun on a schedule.
What makes shades feel automatic
- Group shades by what they do, not where the motor is: all the west-facing shades, all the bedroom blackouts.
- Put shades in the scenes people already use ("Movie", "Goodnight") rather than on buttons of their own.
- Use a time or sunset schedule for the ones that fade furniture, and leave the rest manual.
More on the control side of buying shades: buying motorized shades? Here's the control side nobody quotes. If the dealer who set yours up is gone, we read Lutron systems others programmed and price the work.
